Double walled inside Aluminium / Stainless Steel 304. Outside made of Mild steel and painted in Epoxy Powder Coating/Stainless Steel GMP model. Insulation of 75mm by High Grade Glass wool. (Thermostatic/Digital Control options). Heating Elements are on three sides’ bottom, LHS & RHS Ribs.
With air ventilation on two sides. Perforated adjustable two shelves. Temp range ambient to 250?C with ?1?C accuracy Work on 220/230 volts-50Hz.
Optional:?a) Air Circulation Fan.
b) Microprocessor PID Digital Temp. Controller with timer/Alarm.
c)?PLC controller with 21 CFR Software?and data recorder.
CAT. NO.
TOP RECTANGULAR MM
NO. OF SHELVES
CAPACITY (APPROX.) LITRES
CONNECTED LOAD KW
GI-C8O005/1
300 x 300 x 300 mm
2
28
1.0
GI-C8O005/2
350 x 350 x 350 mm
2
45
1.0
GI-C8O005/3
400 x 400 x 400 mm
2
65
1.5
GI-C8O005/4
450 x 450 x 450 mm
2
95
1.5
GI-C8O005/5
600 x 450 x 450 mm
2
125
2.0
GI-C8O005/6
600 x 600 x 600 mm
2
224
2.0
GI-C8O005/7
900 x 600 x 450 mm
2
252
2.0
GI-C8O005/8
900 x 600 x 600 mm
2
336
3.0
GI-C8O005/9
900 x 900 x 900 mm
3
720
4.5
Note :?Please ask for other capacities of your requirement. GMP Model inner and outer ss complete also available.
